**These bikes are shipped unassembled. Bikes should be assembled by an authorized bicycle retailer**
The Diamondback Motown 27.5” mountain bike is made for tearing up the trails. The lightweight hardtail design, quality Shimano components including a Shimano cassette and 24-speed drivetrain provides the rider with a rugged bike that is made for mountain biking. Add the hydraulic disc brakes and you have even stronger stopping power when you need it to give you confidence on those descents.
FEATURES
- Lightweight 6061 T6 aluminum frame with Diamondback's formed tubing features optimised wall thickness for a balance of strength, weight, and stiffness that translates to a responsive, and reliable ride
- Vaxa 100mm travel front suspension fork with adjustable preload soaks up the bumps and offers smooth and confident control over various terrain
- 27.5" x 2.25" aggressive MTB tires for traction that will bite into any trail conditions
- Tektro hydraulic disc brakes provide immediate stopping power and easy modulation to control your speed in any conditions
- Shimano Rapid Fire and Tourney 24 speed drivetrain offers precise and deliberate shifting so you can tackle new terrain with confidence
- Easy and dependable resin flat pedals so you can get on your bike and ride without worry of any need for specialty bike footwear
- CAVU Comfort-Mountain saddle is equipped with a quick release seat post clamp so it's always easy to find the perfect saddle height.
- CAVU Lock on grips for a confident and reliable connection point in wet or dry conditions
SPECIFICATIONS
- FRAME
- Frame: 6061 T6 heat treated aluminum frame
- Rear Shock: N/A
- Fork: Vaxa 100mm travel, with pre-load adjust
- Cable Routing: External guided w/ full length housing
- DRIVETRAIN
- Rear Derailleur: Shimano Tourney TX800, 8 speed
- Front Derailleur: Shimano TY700
- Shifters: Shimano SL-M315 Rapid Fire 3x8 speed
- Cog Set: Shimano Hyperglide HG318, 8 speed cassette
- Chain: KMC Z8.3
- Crankset: ProWheel Alloy, 9/16*170MM
- Bottom Bracket: Gineyea BB73-68, square taper, sealed cartridge
- COMPONENTS
- Front Brake: Tektro HD-M275 Hydraulic, 160mm rotor
- Rear Brake: Tektro HD-M275 Hydraulic, 160mm rotor
- Brake Levers: Tektro HD-M275 Hydraulic, w/ reach adjust
- Headset: Neco H-148, 1-1/8" threadless, Semi-integrated
- Seat post: CAVU 27.2mm x 300mm Alloy
- COCKPIT
- Handlebar: CAVU, 31.8mm*760mm
- Stem: CAVU Alloy, 80mm, 7 degree rise
- Saddle: CAVU MTB
- Pedals: 9/16" Resin body, flats
- Grips: CAVU Lock-on w/ closed end
- WHEELS/TIRES
- Rims: CAVU Aluminum double wall, 36 hole, 27.5"
- Front Tire: 27.5" x 2.25" for all-terrain
- Rear Tire: 27.5" x 2.25" for all-terrain
- Tubeless Ready: No
- Front Hub: Steel with Quick Release
- Rear Hub: Alloy w/ quick release
